Technical Specifications
80PLUS® : Bronze
Form Factor : Intel ATX 12 V
Dimensions : 140 mm (L) x 150 mm (W) x 86 mm (H)

Fan Information
Fan Size : 120 mm
Fan Control : Seasonic S2FC
Fan Bearing : Sleeve bearing
Life Expectancy : 30,000 hours at 40 °C, 15 % - 65 % RH

Cable Information
Modularity : Fixed cable
Cable type : Flat black cables

Electrical Features
Operating Temperature : 40 °C
MTBF @ 25 °C, excl. fan : 100,000 hours
AC Input : Full Range
Protection : OPP, OVP, UVP, SCP

Safety and Environmental
Safety and EMC : cTUVus, TUV, Gost-R, CB , BSMI, CCC, CE, FCC, C-tick
Environmental Compliance : Energy Star, RoHS, WEEE, REACH
Warranty : 5 Years

Power Output
AC Input :
Voltage: 110 V - 240 V
Current: 8 A - 4 A
Frequency: 50 Hz - 60 Hz
DC Output
Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 18 A 18 A 40 A 0.3 A 2.5 A
90 W 420 W 3.6 W 12.5 W
Total continuous power 500 W

Connector Connector Count Cable Length
Main Power (24/20 pins) 1 1 x 550 mm - attached
CPU (8/4 pins) 1 1 x 600 mm - 8/4 pins attached
PCIe (8/6 pins) 2 1 x 550 + 150 mm - 8/6 pins attached
SATA 4 2 x 400 + 120 mm - attached
Peripheral 3 1 x 450 + 120 + 120 mm - attached
Floppy 1 1 x 120 mm - end connector of the peripheral cable
