GPU :
Radeon™ RX 5600 Graphics
2nd Gen 7nm GPU
RDNA Architecture
Engine Clock :
Boost Clock: Up to 1750 MHz
Game Clock: Up to 1615 MHz
Game Clock is the expected GPU clock
Stream Processor : 2304
Memory Size/Bus : 6GB/192 bit GDDR6
Memory Clock : 14 Gbps Effective
Displays : Maximum 4 Displays
Resolution : HDMI™:
4096×2160@60Hz
DisplayPort1.4: 5120×2880@60Hz
Interface : PCI-Express 4.0
Output :
1x HDMI
3x DisplayPort
BIOS Support : Dual UEFI
API :
Vulkan®
OpenGL® 4.6
OpenCL 2.0
DirectX® : 12
Shader Model : 6.4
Game Index : Extreme 1080P, 1440P Entry
Cooling :
Dual-X Cooling
Dual Fan
Two-Ball Bearing
Form Factor :
2.3 slot, ATX
Dimension: 254 x 135 x 46.5(mm)
Power Consumption : 160W
