SPECIFICATION
Product Name AIDOS / AIDOS BLACK
Product Number 0P105246 [0R10A00077] / 0R100009 [0R10A00009]
Dimension [W×D×H] 95×55×136 mm
Weight 325 g [Heat Sink Only]
Thermal Resistance 0.127 °C/W
Heat Sink
Base Material CPU Direct Contact [C.D.C.]
Fin Material Aluminum Alloy; Solder-less fins assembly
Heat-pipe
SPEC Φ6mm
Q'ty 4 pcs
Fan
Dimension [W×H×D] 92×92×25 mm
Voltage Rating 12V
Starting Voltage 7V
Speed 1000~2200 RPM [PWM controlled]
Bearing Type Sleeve Bearing
Air Flow 22.1~48.6 CFM
Air Pressure 0.73~3.53 mmH2O
Life Expectance 40,000 hrs
Noise Level 28.87 dBA [Max.]
Connector 4 pin with PWM
APPLICATION
Intel® All Socket LGA 2066/201x/1366/115x/1200/775 CPU (Core™ i3 / i5 / i7 / i9 CPU)
AMD® All AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1 CPU
