Deskripsi
Include Tas
----------------
Specifications of Main Parts
LCD
Size : 0.55” (C2 Fine)
Driving Method : Poly-silicon TFT active matrix
Pixel Number : 786,432 dots (1024 x 768) x 3
Native Resolution : XGA
Aspect Ratio 4:3
Pixel Arrangement : Cross stripe
Light Source
Lamp Type : 210 W UHE
Life (Normal / Eco) : 6,000 hours / 12,000 hours
Projection Lens
Type : Optical Zoom (Manual) / Focus (Manual)
F-Number : 1.49 – 1.72
Focal Length : 16.9 – 20.28 mm
Zoom Ratio : 1.0 - 1.2
Throw Ratio : 1.48 – 1.77
Projection Technology
Projection Technology : RGB liquid crystal shutter projection system (3LCD)
Brightness
White Light Output (Normal/Eco) : 3,800 lm / 2,500 lm
Colour Light Output : 3,800 lm
Light Output (Center)*2 : 4,000 lm
Konektivitas:
Jaringan : Wireless LAN: Optional (with ELPAP11)
Digital Input : HDMI Type A : 2 (HDCP 1.4)
USB Input :
USB Type A : 1 (480Mbps for PC Free, Firmware Update, Copy OSD Settings or 5V/2A Power Supply)
USB Type B : 1 (For Firmware Update, Copy OSD Settings)
Contrast Ratio
Contrast Ratio : 16,000:1
Screen Size (Projected Distance)
Zoom : Wide : 30” – 300” [0.89 – 9.12 m]
Zoom : Tele : 30” – 300” [1.07 - 10.95 m]
Geometric Correction:
Vertical/Horizontal Keystone : ±30° / ±30°
Operating Temperature:
Low Altitude (0 - 2,286m/7,500ft) : 5 - 40 °C
High Altitude (Over 2,286m/7,500ft) : 5 - 35 °C
20% - 80% Humidity, No Condensation
Operating Altitude
Over 1,500m/4,921ft with High Altitude Mode : 0 - 3,048m (0 -10,000ft)
Start-Up Period
Less than 7 seconds (Epson Logo); Warm-up Period: 30 seconds
Cool Down Period
Cool Down Period : Instant Off
Internal Speaker(s)
Sound Output : Monaural 2W x 1
Weight
Berat : Approx. 2.5kg
Air Filter
Maintenance Cycle*3 : 6,000 hours (Normal) / 12,000 hours (Eco)
Fan Noise
Fan Noise (Normal / Eco) : 37dB / 28dB
Power Consumption (220-240V)
Lamp (Normal / Extended) :
Normal : 332 W
Extended : 231 W
Standby (Normal / Eco) : 2.0 / 0.3 W
Direct Power On / Off
Direct Power On / Off : Yes
Dimension Excluding Feet
Dimension Excluding Feet (W x D x H) : 302 x 234 x 77 mm
Wireless Specifications (Optional Wireless LAN)
Supported Speed for Each Mode * : IEEE 802.11a/b/g/n
Supported Mode : Infrastructure, Simple AP (Wi-Fi Direct)
Supported Security Type :
Infrastructure: Open, WPA2 / WPA3-PSK
Simple AP (Wi-Fi Direct): OPEN, WPA2-PSK (AES)
