Model Name: MAG Z590 TOMAHAWK WIFI
CPU Support: Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel®
Core™ Processors, Pentium® Gold and Celeron® Processors
CPU Socket: LGA 1200
Chipset: Intel® Z590 Chipset
Graphics Interface:
1x PCIe 4.0 x16 slot, 1x PCIe 3.0 x16 slot
Support 2-way AMD® CrossFire™ Technology
Display Interface: Support 4K@60Hz as specified in HDMI 2.0b, DisplayPort 1.4
– Requires Processor Graphics
Memory Support: 4 DIMMs, Dual Channel DDR4-5333(OC)
Expansion Slots: 2x PCIe 3.0 x1 slots
Storage: 1x M.2 Gen4 x4 64Gb/s slot, 2x M.2 Gen3 x4 32Gb/s slots,
Support Intel® Optane™ Technology,
6x SATA 6Gb/s ports
USB Ports: 1x USB 3.2 Gen 2x2 20Gbps (Type-C),
2x USB 3.2 Gen 2 10Gbps (Type-A + Type-C),
6x USB 3.2 Gen 1 5Gbps (Type-A),
6x USB 2.0
LAN: ntel® I225-V 2.5G LAN
Wireless/Bluetooth: Intel® Wi-Fi 6E AX210, Bluetooth 5.2
Audio: 8-Channel(7.1) HD Audio with Audio Boost 5
