MODEL : MPY-750V-AFBAG
ATX VERSION : ATX 12V V2.52
PFC : Active PFC
INPUT VOLTAGE : 100-240V
INPUT CURRENT : 10-5A
INPUT FREQUENCY : 50-60Hz
DIMENSIONS (L X W X H) : 160 x 150 x 86 mm
FAN SIZE : 135mm
FAN BEARING : FDB
FAN SPEED : 1545 RPM
NOISE LEVEL @ 20% : 0 dBA
NOISE LEVEL @ 50% : 23.6 dBA
NOISE LEVEL @ 100% : 32.5 dBA
EFFICIENCY : 90% @ Typical Load
80 PLUS RATING : 80 PLUS Gold
ERP 2014 LOT 3 : Yes
OPERATING TEMPERATURE : 0-50°C
POWER GOOD SIGNAL : 100 - 500 ms
HOLD UP TIME : 17ms
MTBF : >100,000 Hours
PROTECTIONS : OVP, OPP, SCP, OCP, UVP, OTP
REGULATORY : CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
ATX 24-PIN CONNECTORS : 1
EPS 4+4 PIN CONNECTORS : 1
EPS 8 PIN CONNECTOR : 1
SATA CONNECTORS : 12
PERIPHERAL 4-PIN CONNECTORS : 4
PCI-E 6+2 PIN CONNECTORS : 4
SERIES : V Gold Series
80 PLUS : Gold
MODULAR : Full Modular
WATTAGE : 500 to 750W
