Model Name : ECA3500ABA-RGB
Dimensions (D x W x H) : 478 x 223 x 566 mm
Material : 0.8mm SPCC
M/B Type : ATX, Micro ATX, Mini ITX
I/O :
1 x USB3.1 Gen2 Type C, 1 x USB3.0, 2 x USB2.0, HD Audio, Fan speed control,
LED brightness control, LED mode control, Lumi switch
5.25'' Drive Bays : 1
3.5'' Drive Bays : 2
2.5'' Drive Bays : 6 ( 2 x Converted from 3.5” trays )
Expansion Slots : 7
Fan Slots - Front : 3 x 120mm ( 3 x 120mm SquA RGB fans pre-installed )
Fan Slots - Top : 2 x 140mm or 3 x 120mm
Fan Slots - Rear : 1 x 140mm or 1 x 120mm ( 1 x 140mm fan pre-installed )
Fan Slots - Side : 2 x 120mm
Radiator Support - Front : 360mm / 240mm ( 62mm clearance )
Radiator Support - Top : 360mm / 280mm / 240mm ( 63mm clearance )
Radiator Support - Rear : 140mm / 120mm
Radiator Support - Side : 240mm
PSU Support : Standard ATX Type
Clearance - VGA card : 420mm (280mm with side fan)
Clearance - CPU Cooler : 175mm
