Power Source : 220 - 240 V AC, or 24 V DC
Rated Output : 120 W
Power Consumption : 124 W (AC operation EN60065),
8 A (DC operation at rated output)
Frequency Response : 50 - 20,000 Hz (±3 dB)
Distortion : Less Than 1% at 1 kHz, 1/3 rated power
Input : MIC 1 - 3: -60 dB* (1.0 mV), 600 Ω, balanced, phone jack
AUX 1,2: -20 dB* (100 mV), 10 kΩ, unbalanced, RCA pin jack
Output : Speaker out: Balanced (floating)
High impedance: 83 Ω (100 V), 42 Ω (70 V)
Low impedance: 4 Ω (22 V)
Rec out: 0 dB* (1.0 V), 600 Ω, unbalanced, RCA pin jack
Phantom Power : DC +21 V (MIC 1)
S/N Ratio : More Than 60 dB
Tone Control : Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Muting MIC 1: Mutes other input signals by 0 - 30 dB attenuation
Indicator : Power LED, signal LED, peak LED
Finish : Panel: ABS resin, black
Case: Steel plate, black
Dimensions : 420 (W) × 101 (H) × 360 (D) mm (16.5" × 4.0" × 14.2")
Weight : 10.8 kg (23.81 lb)
